All in One Hybid Inverter Deye 100KW 3Phase With Baterai Lifepo4 215 kWh HVDC System High Performance

Datasheet Sistem Hybrid DEYE HVDC 50KW 3 Phase – DEYE + Battery LiFePO4 178kWh

Spesifikasi Sistem

Komponen Spesifikasi Inverter Deye Hybrid HVDC 3 Phase – 100KW

• Tipe Inverter Hybrid (On-grid + Off-grid + Backup)
• Model SUN-100K-SG04HP3-EU (HV)
• Input PV Maksimum 60KW (maks. 2 MPPT, 4 input)
• Tegangan PV Maks.1100V DC
• Tegangan PV Mulai 200V
• Rentang MPPT200V – 1000V
• Daya Output AC 100,000W (3 Phase, 400V AC)
• Efisiensi Maks.98.2%Frekuensi50/60Hz (Auto Detect)
• Proteksi Anti-islanding, Overvoltage, Short Circuit, Surge Protection
• Komunikasi RS485, CAN, WiFi, LAN, GPRS (opsional)
• Fitur TambahanSmart Meter Support, ATS Ready, Parallel up to 10 units

Spesifikasi Baterai LiFePO4 HV

Komponen Spesifikasi

• Tipe Baterai Lithium Iron Phosphate (LiFePO4) – High Voltage Stackable
• Kapasitas Total 215 kWh
• Jumlah Unit 3 Unit Series + 1 BCU
• Tegangan Sistem 450~657 DC
• Depth of Discharge (DOD)90%
• Life Cycle>6000 siklus @ 80% DOD
• Proteksi Internal BMS: Overcharge, Overdischarge, Overcurrent, Overtemp
• Komunikasi CAN/RS485 (kompatibel dengan inverter Deye HVDC)
