SUN-14/15/16/18/20K-SG05LP3-EU-SM2 | 14-20kW | Three Phase | 2 MPPT | 20kW Hybrid Inverter | LV Battery Supported

Main advantages of DEYE Three Phase Hybrid EU Inverter :

• High Efficiency: DEYE inverters are designed to maximize energy conversion, leading to improved overall system performance.
• Versatile Hybrid Functionality: They support both grid-tied and off-grid applications, providing flexibility for various energy needs.
• Integrated Battery Management: These inverters can seamlessly integrate with battery storage systems, allowing users to store excess energy for later use.
• Smart Monitoring: DEYE inverters often come with advanced monitoring features, enabling real-time tracking of energy production and consumption through mobile apps or web platforms.
• Robust Design: Built for durability, they are suitable for diverse environmental conditions and have a long lifespan.
• Scalability: Their modular design allows for easy expansion, making them suitable for both residential and commercial applications.
• Low Harmonic Distortion: This helps maintain better power quality and reduces potential issues with connected devices.
• User-Friendly Interface: The inverters typically feature intuitive displays and controls for easier operation and setup.
• Grid Support Features: Advanced functions, such as voltage and frequency ride-through, enhance grid stability and reliability.

These features enhance the overall value and versatility of the DEYE Three Phase Hybrid EU Inverter, making it an attractive option for both residential and commercial energy solutions.

Short summary of technical specifications:

20 kW

• PV String Input Data
• Maximum PV input power: 26kW
• Maximum PV input voltage: 800V
• MPPT Voltage range: 160V-650V
• Maximum operating PV input current: 36+20A
• Maximum input short-circuit current: 54+30A
• Number of MPPTs: 2
• Number of string per MPPT: 2+2
• Battery Input/Output Data
• Battery voltage range: 40-60V
• Maximum charging/discharging current: 350A
• Number of battery input ports: 1
• AC Input/Output Data
• Rated AC output active power: 20kW
• Maximum AC input/output apparent power: 22kVA
• Rated AC input/output current: 31.4A / 29A
• Maximum AC input/output current: 33.4A / 31.9A
• Maximum three-phase unbalanced output current: 45.5A / 43.5A
• Maximum continuous AC passthrough (grid to load): 70A
• Grid connection form: 3L+N+PE
• Rated AC input/output voltage/range: 220/380V; 230/400V; 0.85UN-1.1Un
