Hybrid Inverter PSW Ongrid Offgrid Bidirectional 48v 3600watt 3.6Kw Power Charger Solar

Specifications : Model : hybrid ongrid 3600watt * Rated Power : 3600W * Operating Mode : Flexible setup via upper computer software or LCD interface PV INPUT Max. input power : 4500W Rated input voltage : 360Vdc Max. input voltage : 500Vdc Start-up voltage : 115Vdc Initial feeding voltage : 150Vdc MPPT voltage range : 250Vdc - 450Vdc Max. input current : 18A PV short circuit current : 18A Number of MPPT : 1 BATTERIES Battery type : LFP battery Rated voltage : 51.2Vdc Voltage range : 46.4Vdc - 57.6Vdc Battery type : VRLA AGM maintenance - free battery Rated voltage: 48Vdc Voltage range : 40Vdc - 58Vdc Battery capacity : 100Ah - 120 Ah optimized Max. charger power : 1425W Max. charge current : 25 A (5A / 10A / 15A / 20A / 25A settable) Charging curve : 3-Stage Max. charge efficiency : 94 % Rated discharge power : 2000W Max. discharge current : 100A Max. discharge efficiency : 94% AC OUTPUT Rated output power : 3600VA / 3600W Rated output voltage : 230Vac (208 / 220 / 240 settable) Rated output current : 15.6A (17.3A / 16.4A / 15A ) Output voltage range : 170Vac - 280Vac Rated output frequency : 50Hz / 60Hz Output frequency tolerance : 50 -+ 5Hz / 60 -+ Hz Power factor : 0.8 leading - 0.8 lagging THD : lt; 3% EPS OUTPUT Rated EPS power : 2000VA / 2000W Rated EPS voltage : 230Vac (208 / 220 / 240 settable ) Rated EPS current : 8.7A (9.6A / 9.1A / 8.3A) EPS voltage range : 184Vac - 264.5Vac Rated frequency : 50Hz / 60Hz Frequency precision : -+ 1% Voltage precision : -+ 1% Transient recovery time : lt; 40ms Crest factor : 3 : 1 Linear load waveform distortion : lt; 3% Short circuit current : 45A (100ms) TRANSFER TIME EPS mode - gt;On-grid mode : 0 ms On-grid mode- gt;EPS mode : 10 ms EFFICIENCY MPPT efficiency : 99% Max. PV efficiency : 96% GENERAL DATA Communications : USB/RS485/SNMP (optional) Weight : 15 Kg Dimenssions : 410 x 470 x 123 mm
